Start-up
After a successful adaptation run, each heating
zone is shown in the display according to the val-
ve position.
6.4 Teaching-in
Please read this entire section before starting
the teach-in procedure.
To integrate the floor heating actuator into your system
and enable it to communicate with other devices, you
must teach it in first.
You can either pair the floor heating actuator directly with
other Homematic IP devices (e.g. the wall thermostat or
the Multi IO Box) or teach it in to the Homematic IP Ac
-
cess Point. After pairing, the device is configured at the
wall thermostat. After teaching-in to the Access Point, the
device is configured via the Homematic IP app.
6.4.1 Pairing with a Homematic IP Wall Thermostat
Please make sure you maintain a distance of at
least 50cm between the devices.
You can cancel the pairing procedure by briefly
pressing the system button (A) again. This will be
indicated by the device LED (A)lighting red.
If no pairing operations are carried out, pairing
mode is exited automatically after 3 seconds.

Homematic IP HmIP-FALMOT-C12 Specifications

General

Input voltage	24/230 V
Input frequency	50 Hz
Power source type	AC, DC
Maximum switching capacity	0.2 W
Frequency	869.65 MHz
Cable length	1.5 m
Display type	LCD
Product type	Heating actuator
Product color	White
Built-in display	Yes
Channels quantity	12 channels
Maximum outdoor range	320 m
International Protection (IP) code	IP20
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	52 mm
Width	242 mm
Height	85 mm
Weight	440 g
Package depth	281 mm
Package width	184 mm
Package height	97 mm
Package weight	917 g
