Page #49 background imageLoading...
Page #49 background image
49
Start-up
5.2 DIN rail mount
For mounting the floor heating actuator to a DIN rail,
please proceed as follows:
Place the floor heating actuator onto the DIN rail
(see figure 4).
Latch the floor heating actuator by pressing the
spring latches (G) upwards (see figure 4).
Make sure that the spring latches are completely
latched and that the device is seated solidly on
the rail.
6 Start-up
6.1 Installation instructions
Please read this entire section before starting to
install the device.
For installing the floor heating actuator into a
power distribution panel it has to be mounted in
accordance with VDE 0603, DIN 43871 (low-volt-
age sub-distribution board), DIN 18015-x. In this
case, the installation must be made on a mount-
ing rail (DIN rail) according to EN50022. Installa-
tion and wiring have to be performed according
to VDE 0100 (VDE 0100-410, VDE 0100-510 etc.).
Please consider the technical connection re-
quirements (TAB) of your energy supplier.
