48
Mounting
tions provided by the system in combination with other
components are described in the Homematic IP User
Guide. All current technical documents and updates are
provided at www.eQ-3.com.
5 Mounting
You can flexibly mount the floor heating actuator to a
wall using the supplied screws or to a DIN rail.
5.1 Screw mounting
For mounting the floor heating actuator using screws,
please proceed as follows:
Please select a suitable mounting location close
to your heating manifold.
Make sure that no electricity or similar lines run in
the wall at this location!
Use a pen to mark the positions of the two bore
holes with a distance of 120 mm on the wall (see
figure 3).
Use a suitable bit to drill the 6 mm holes as il-
lustrated.
Use the supplied screws and plugs to fasten the
floor heating actuator (see figure 3).
