Page #50 background image
50
Start-up
Please observe the hazard information in section
„2 Hazard information“ on page 42.
Permitted cable cross sections for the cable bushings of
the floor heating actuator are (see figure 2):
Cable bushings Cable cross section [mm]
1 (K) > 8.0
2 (L) > 5.5
3 (M) > 3.6
4 (N) > 4.4
Permitted cable cross sections for connecting to the
connecting terminals (H) of the floor heating actuator:
Rigid cable: 0.12 – 0.50 mm
6.2 Installation
You can connect the floor heating actuator to a
230 V socket using the supplied mains cable and
thus provide it with power, or you can use the
connection terminal (H) to connect 24 V
DC
(SELV).
To install the floor heating actuator, please proceed as
follows:
