Homematic IP HmIP-FALMOT-C12 User Manual

55
Start-up
• You can add the new floor heating actuator to
other devices such as the wall thermostat or the
Multi IO Box. Simply activate the pairing mode of
the floor heating actuator first and of the device
you want to pair afterwards. For further informa-
tion, please refer to the user manual of the corre-
sponding device.
6.4.4 Teaching-in to the Homematic IP Access Point
First set up your Homematic IP Access Point via
the Homematic IP app to enable operation of
other Homematic IP devices within your system.
For further information, please refer to the oper-
ating manual of the Access Point.
You can connect the device either to the Access
Point or to the Homematic Central Control Unit
CCU2/CCU3. For detailed information, please re-
fer to the Homematic IP User Guide, available for
download in the download area of www.eQ-3.de.
To teach-in your floor heating actuator to the Access
Point, please proceed as follows:
• Open the Homematic IP app on your smart-
phone.
• Select the menu item “Teach-in device”.
• Briefly press the system button (A) until the LED
(A) quickly starts flashing orange (see figure 6).

Homematic IP HmIP-FALMOT-C12 Specifications

General

Input voltage	24/230 V
Input frequency	50 Hz
Power source type	AC, DC
Maximum switching capacity	0.2 W
Frequency	869.65 MHz
Cable length	1.5 m
Display type	LCD
Product type	Heating actuator
Product color	White
Built-in display	Yes
Channels quantity	12 channels
Maximum outdoor range	320 m
International Protection (IP) code	IP20
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	52 mm
Width	242 mm
Height	85 mm
Weight	440 g
Package depth	281 mm
Package width	184 mm
Package height	97 mm
Package weight	917 g
