Homematic IP HmIP-FALMOT-C12 User Manual

56
Start-up
The teach-in mode of the selected channel re-
mains activated for 3 minutes.
You can manually start the teach-in mode for an-
other 3 minutes by pressing the system button (A)
briefly (see figure 6).
• Your device will automatically appear in the
Homematic IP app.
• To confirm, please enter the last four digits of the
device number (SGTIN) in your app or scan the
QR code. Therefore, please see the sticker sup-
plied or attached to the device.
• Please wait until teach-in is completed.
• If teaching-in was successful, the LED lights up
green. The device is now ready for use.
• If the LED lights up red, please try again.
• Select the desired solution for your device.
• In the app, give the device a name and allocate
it to a room.

Homematic IP HmIP-FALMOT-C12 Specifications

General

Input voltage	24/230 V
Input frequency	50 Hz
Power source type	AC, DC
Maximum switching capacity	0.2 W
Frequency	869.65 MHz
Cable length	1.5 m
Display type	LCD
Product type	Heating actuator
Product color	White
Built-in display	Yes
Channels quantity	12 channels
Maximum outdoor range	320 m
International Protection (IP) code	IP20
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	52 mm
Width	242 mm
Height	85 mm
Weight	440 g
Package depth	281 mm
Package width	184 mm
Package height	97 mm
Package weight	917 g
