Homematic IP HmIP-FALMOT-C12 User Manual

57
Configuration via the HomematicIP Wall Thermostat
7 Configuration via the Homema-
ticIP Wall Thermostat
The Homematic IP Floor Heating Actuator can be
configured via the Homematic IP Wall Thermostat
(HmIP-WTH-2), via the Homematic IP Access Point
together with the smartphone app or via the WebUI
of the Homematic Central Control Unit CCU2/
CCU3.
To configure the floor heating actuator using the wall
thermostat, please proceed as follows:
• Press and hold down the control wheel of the
wall thermostat to open the configuration menu.
• Select the
symbol by turning the control
wheel and confirm by pressing the control wheel
briefly.
• If the wall thermostat is connected to more than
one floor heating actuator, please select the re-
quired floor heating actuator („FALx“) using the
control wheel.
• Please define if you want to configure the device
parameters (”UnP1/UnP2”) or the channel param-
eters (”ChAn”).
All the settings that are made under “UnP1/UnP2”
will be applied to the entire device. All settings
that are made under “ChAn” will be applied to the
single channels of the device.

Homematic IP HmIP-FALMOT-C12 Specifications

General

Input voltage	24/230 V
Input frequency	50 Hz
Power source type	AC, DC
Maximum switching capacity	0.2 W
Frequency	869.65 MHz
Cable length	1.5 m
Display type	LCD
Product type	Heating actuator
Product color	White
Built-in display	Yes
Channels quantity	12 channels
Maximum outdoor range	320 m
International Protection (IP) code	IP20
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	52 mm
Width	242 mm
Height	85 mm
Weight	440 g
Package depth	281 mm
Package width	184 mm
Package height	97 mm
Package weight	917 g
