Homematic IP HmIP-FALMOT-C12 User Manual

51
Start-up
• Open the cover (E) by pulling it downwards (see
figure 5).
• Connect (optionally) a 24 V
DC connecting cable
to the terminal (H). To connect and disconnect
the individual wires, press the orange actuator
button using a small screwdriver.
• Connect the connecting cables of the valve ac-
tuators of your heating circuits to the connecting
sockets (I).
• Connect (optionally) the connecting cable of
your expansion box to the connecting socket (J).
• Close the cover again by placing the cover in the
guide rail provided and pushing the cover up-
wards.
• Plug the power cable (optional) into a socket.
6.3 Behaviour after switching on the mains
voltage
After the mains voltage is switched on, the display
(B) lights up permanently.
If the device has not yet been connected, teach-in mode
will be activated during the first 3 minutes after the mains
voltage has been switched on. You will find further infor-
mation about connecting your device in the next section.
All connected valve actuators are opened fully one after
the other. The valve actuators then carry out an adaptati-
on run to determine the valve closing position.

Homematic IP HmIP-FALMOT-C12 Specifications

General

Input voltage	24/230 V
Input frequency	50 Hz
Power source type	AC, DC
Maximum switching capacity	0.2 W
Frequency	869.65 MHz
Cable length	1.5 m
Display type	LCD
Product type	Heating actuator
Product color	White
Built-in display	Yes
Channels quantity	12 channels
Maximum outdoor range	320 m
International Protection (IP) code	IP20
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	52 mm
Width	242 mm
Height	85 mm
Weight	440 g
Package depth	281 mm
Package width	184 mm
Package height	97 mm
Package weight	917 g
