67
Troubleshooting
1x orange and 1
x green lighting
Test display Once the test dis-
play has stopped,
you can continue.
10.3.2 Error codes in the display
Flashing code Meaning Solution
Open-end wrench
flashes at intervals
of 0.5 s
Adaptation run
at the heating
zone could not
be carried out
Check that the
actuator is cor-
rectly mounted
on the valve
and that the
connector is
plugged into
the right socket.
Exclamation mark
flashes at intervals
of 0.5 s
The heating
zone is in
emergency
mode
Perform a com-
munication test,
reposition the
wall thermostat
if necessary,
change wall
thermostat bat-
teries or replace
defective wall
thermostat.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Homematic IP HmIP-FALMOT-C12 and is the answer not in the manual?

Homematic IP HmIP-FALMOT-C12 Specifications

General IconGeneral
Input voltage24/230 V
Input frequency50 Hz
Power source typeAC, DC
Maximum switching capacity0.2 W
Frequency869.65 MHz
Cable length1.5 m
Display typeLCD
Product typeHeating actuator
Product colorWhite
Built-in displayYes
Channels quantity12 channels
Maximum outdoor range320 m
International Protection (IP) codeIP20
Operating temperature (T-T)0 - 50 °C
Weight and Dimensions IconWeight and Dimensions
Depth52 mm
Width242 mm
Height85 mm
Weight440 g
Package depth281 mm
Package width184 mm
Package height97 mm
Package weight917 g
