Homematic IP HmIP-FALMOT-C12 User Manual

62
Manual operation
Configuration
for rooms
P054 0
1
2
Standard room
(default)
Room with fireplace
Room with towel
rail heating
Selection of
heating system
P055 0
1
2
Standard floor
heating
(default)
Low energy floor
heating
Radiator
For further information regarding the configurati-
on, please refer to the user manual of the Home-
matic IP Wall Thermostat (HmIP-WTH-2).
8 Manual operation
For installation and test purposes, the adaptation runs can
be restarted manually at the individual heating zones or
individual heating zones can be opened or closed.
• To start an adapter run manually, proceed as fol-
lows:
• Select the required channel using the channel
button (D) (see figure 7).
• Press the select button (C) until the open-end
wrench appears at the selected channel in the
display (B) (see figure 7).

Homematic IP HmIP-FALMOT-C12 Specifications

General

Input voltage	24/230 V
Input frequency	50 Hz
Power source type	AC, DC
Maximum switching capacity	0.2 W
Frequency	869.65 MHz
Cable length	1.5 m
Display type	LCD
Product type	Heating actuator
Product color	White
Built-in display	Yes
Channels quantity	12 channels
Maximum outdoor range	320 m
International Protection (IP) code	IP20
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	52 mm
Width	242 mm
Height	85 mm
Weight	440 g
Package depth	281 mm
Package width	184 mm
Package height	97 mm
Package weight	917 g
