5.4 Install Door/window sensor
Base and magnet should be installed maximum 5 mm apart. The magnet can be placed at a 90-degree
angle in front of the base but never more than 5 mm away.
Place the double sided tape
here
Self-supervision – hold this
button down while the
battery is inserted to turn
status signal on/off.
Reed relay (inside, registers
the magnetic field)
