Technical Information
232
Specifications
Chassis & Suspension
caster 2°
trail 6 mm (0.2 in)
tyre size, front AT25 × 8-1211 MAXXIS M975
tyre size, rear AT25 × 10-1211 MAXXIS M978
tyre pressure,
front & rear
(cold)
front:
30 kPa (4.4 psi)
rear:
30 kPa (4.4 psi)
Electrical
battery GYZ16H
12 V – 16 Ah (10HR)
generator 0.481 kW/5,000 min
–1
(rpm)
Lights
headlight 12 V 35/35 W × 2
assist headlight 12 V 45 W
brake/tail light LED
neutral indicator LED
reverse indicator LED
high coolant
temperature indicator
LED
PGM-FI indicator LED
differential lock
indicator
LED
PS (Electric Power
Steering) indicator
(TRX500FM2 only)
LED
