Technical Information
233
Specifications
Fuses
main 1 40 A
main 2 10 A
other 20 A × 4, 10 A
EPS (Electric Power
Steering) (TRX500FM2
only)
40 A
Torque Specification
engine oil drain
bolt
25 N·m (2.5 kgf·m, 18 lbf·ft)
engine oil filter
cover bolts
10 N·m (1.0 kgf·m, 7 lbf·ft)
rear final gear oil
drain bolt
12 N·m (1.2 kgf·m, 9 lbf·ft)
rear final gear oil
fill cap
12 N·m (1.2 kgf·m, 9 lbf·ft)
rear final gear oil
level check bolt
12 N·m (1.2 kgf·m, 9 lbf·ft)
front final gear
oil drain bolt
12 N·m (1.2 kgf·m, 9 lbf·ft)
front final gear
oil fill cap
12 N·m (1.2 kgf·m, 9 lbf·ft)
rear brake drain
bolt
12 N·m (1.2 kgf·m, 9 lbf·ft)
wheel nuts 64 N·m (6.5 kgf·m, 47 lbf·ft)
