Accenta/Optima Engineers Manual
36
2 = Timed Zones
A zone programmed as Timed would be used to protect the main entry/exit door of the entry route.
LCD Keypad:
NOTE: Pressing the number toggles the zone ON or OFF
While in Engineer program mode, to set up zones as timed,
Press to give a choice of programs or press
until P>Programs is displayed then press .
Select program 1, 2 or 3.
The first screen to appear is Program Edit Used Zones.
Press [2] to enter into Timed Zones. The first zone can now be
set as timed or untimed.
To edit the other zones press [Number] or to go to a
particular zone.
Press three times to leave menu.
LED Keypad:
NOTE: Pressing the number toggles the zone ON or OFF
While in Engineer program mode, to set up zones as timed,
Press to give a choice of programs. LED’s 1, 2 and 3 are
flashing.
Select program [1, 2 or 3]. If program 1 is selected, LED 1 is ON.
Press [2] to enter into Timed Zones. The first zone can now be
set as timed or untimed.
To edit the other zones press [Number] to go to a particular zone.
Default settings are shown opposite.
Press three times to leave menu.
Programs (contd)
[2]
1: Descriptor
Timed: YES
P>Select Program
1 2 or 3
P>Program Edit
Used Zones
[Number]
[Number] or
2: Descriptor
Timed: NO
P> Programs
[1]
[2]
12
3
4
5
6
7
8
12
3
4
5
6
7
8
12
3
4
5
6
7
8
[Number]
12
3
4
5
6
7
8
12
3
4
5
6
7
8
