CT45/CT45 XP Mobile Computer Series User Guide 105
Far Field Optical System
• Horizontal FOV: 20°
•Vertical FOV: 12°
DPI can be calculated based on the following formula:
Horizontal DPI = 1280 pixels/width of horizontal field of view (inches)
Vertical DPI = 800 pixels/width of vertical field of view (inches)
N6700 Imager (CT45 XP Only)
Note: Time to Read and Depth of Field are impacted if the barcode symbol is at the edge of
the image.
Guaranteed Specs
Focus Standard Range
Symbology Near Distance Far Distance
3 mils Code 39 mm 129.03 164.1
in. 5.08 6.46
5 mils Code 39 mm 79 270
in. 3.11 10.63
10 mils Code 39 mm 34.04 450.1
in. 1.34 17.72
20 mils Code 39 mm 38.1 674
in. 1.50 26.53
13 mils 100% UPC-A mm 38.1 515
in. 1.50 20.27
13 mils 20% UPC-A mm 83.1 205
in. 3.27 8.07
15 mils Code 128 mm 36.1 572.01
in. 1.42 22.52
10 mils Data Matrix mm 83.1 236
in. 3.27 9.29
5 mils PDF 417 mm 119 177.04
in. 4.68 6.97
6.7 mils PDF 417 mm 96.01 236
in. 3.78 9.29
6.7 mils QR mm 123 147.1
in. 4.84 5.79
