Chapter 3. MOUNTING
3-1
Chapter 3. MOUNTING
3-1 External Dimensions
B-B
37
78.4
110.5
A-A
90.2 91.5
Back plate
Add-on terminal base
Terminal screw
(106x104)
(18)
15
159.5
137
AB
AB
Unit: mm
Mounting bracket 81405411-001
Soft dust-proof cover set (sold separately)
81446087-001
Hard dust-proof cover set (sold separately)
81446083-001
Terminal cover set (sold separately) 81446084-001
96
96
