Chapter 4. WIRING
4-15
● Internal circuit for controller components for connecting external switch inputs
24
21
25
12Vdc
12Vdc
48
41
12Vdc
12Vdc
Standard terminal base
External
switch
input
External
switch
input
Internal circuit Internal circuit
Add-on terminal base
