Monitor Operation
20 E
3
Point Gas Monitor Technical Manual
The screen briefly displays a success message and returns to the main
menu option.
Restore
Success
Temp Menu
The Temp menu allows users to define the maximum temperature for
the device temperature alarm, which can be used to activate the device
connected to the relay.
* Menu *
Temp
Press enter to access the Temp menu, then select either Disable or
Enable.
Temp
Enable
Use the arrow keys to select the temperature scale (either oC or oF) and
press enter to select (the underlined value). This affects local display only
and is not stored in memory—it is a conversion aid.
Limit
oC
• Use the arrow keys to increase or decrease the value to the
desired level and press enter.
Limit
50oC
An alarm (or relay) as chosen at programming time will be triggered when
the temperature reaches the specified level. TEMP LIMIT will display on
the LCD.
The temperature measured represents the monitor’s internal reading
and may differ from external temperatures by up to 10°C.
The monitor does not display temperature readings.
