Periphery components for ESSER FACP
TI 798960.GB0 / 04.20 23
Part No. Detector type Specific detector specifications
*3
800171
*1
Fixed heat detector
Quiescent current @ 9 V DC : 25 µA
Usage temperature : -20 °C ... +50 °C
Specification : EN 54-5 A1S : 2002
VdS approval : G 213068
Declaration of Performance : DoP-21291131101
800177
*1
Fixed heat detector
Quiescent current @ 9 V DC : 25 µA
Usage temperature : -20 °C ... +65 °C
Specification : EN 54-5 BS : 2000
VdS approval : G 213067
Declaration of Performance : DoP-21295131101
800271
*1
Rate-of-rise heat
detector
Quiescent current @ 9 V DC : 25 µA
Usage temperature : -20 °C ... +50 °C
Specification : EN 54-5 A1R : 2002
VdS approval : G 213069
Declaration of Performance : DoP-21293131101
800371
*2
Optical smoke detector
Quiescent current @ 9 V DC : 30 µA
Usage temperature : -20 °C ... +72 °C
Specification : EN 54-7 : 2006
VdS approval : G 213066
Declaration of Performance : DoP-21296131101
800374
*2
O
2
T multisensor detector
Quiescent current @ 9 V DC : 60 µA
Usage temperature : -20 °C ... +65 °C
Specification : EN 54-7 : 2006/-5 B : 2000, CEA
4021
VdS approval : G 213070
Declaration of Performance : DoP-21296131101
800375
*2
OT
blue
multisensor
detector
Operating voltage : 9 V DC ... 42 V DC
Quiescent current @ 9 V DC : 50 µA
Usage temperature : -20 °C ... +50 °C
Specification : EN 54-7 : 2006/-5 A2 : 2002, CEA
4021
VdS approval : G 213065
Declaration of Performance : DoP-21298131101
800379
*2
OT
blue
-LKM-multisensor
detector
Operating voltage : 9 V DC ... 42 V DC
Quiescent current @ 9 V DC : 35 µA
Air velocity range : 1 … 20 m/s
Ambient temperature : -20 °C … +50 °C
Specification : EN 54-27 : 2015
VdS approval : pending
Declaration of Performance : ---
*1
Head sensor type
*2
Smoke
*3
The information applies for the entire series incl. .MAR, .N0, .NU etc.
For further information refer to product catalogue.
