Periphery components for ESSER FACP
TI 798960.GB0 / 04.20 39
6.5 Manual call point - small design (accessories)
Protective kit for MCP and TAL (Part No. 704965)
To protect against accidental activation.
The cover is inserted into the grooves at the side of the
housing upper part and can also be sealed in place.
Mounting frame (Part No. 704967)
With red covering screen for universal wall installation
manual call point
Dimensions: 123 x 123 mm (incl. covering screen)
Plastic operating panel (Part No. 704964)
Can be reset, white.
The plastic operating panel is not destroyed when pressed
and can be reused over and over again for the activation of
the detector.
Fig. 25: Accessories
For further information refer to product catalogue.
