Periphery components for ESSER FACP
50 TI 798960.GB0 / 04.20
7.2 IQ8Wireless gateway
The mounting height of the IQ8Wireless gateway (Part No. 805594.10) for IQ8Quad fire detectors, as device of
the loop, must be coordinated with the type of fire detector which is installed. Additionally the mounting position
of the IQ8Wireless gateway should be selected to ensure a good radio connection (signal strength) between the
IQ8Wireless gateway and the associated IQ8 Wireless devices.
Conventional detector base (Part No. 805590) of an
already installed loop.
IQ8Wireless gateway with cover
IQ8Quad fire detectors without integrated alarm device
Fig. 35: IQ8Wireless gateway
