Honeywell ESSER FACP User Manual

Periphery components for ESSER FACP
24 TI 798960.GB0 / 04.20
5.5 Detector base and options
Detector socket for connection
• to the esserbus
®
/ esserbus
®
PLus of the ESSER-BMZ 800x / IQ8Control / FlexES Control / Compact and
for attaching the automatic fire detector IQ8Quad.
• to the spur lines of the ESSER-BMZ ES Line, detector zones of the esserbus
®
transponder and for attaching
the fire detector ES Detect.
Specifications
*3
Ambient temperature : -20 °C ... +72 °C
Storage temperature : -25 °C ... +75 °C
Humidity :
≤ 95% rel. humidity (non-condensing)
Protection rating : IP 40 with detector
IP 42 with detector + option 805570
IP 43 with detector + option 805572.50 / 805573
Connection terminals : 0.6 mm ... 2 mm
2
Housing : ABS
Colour : white (similar to RAL 9010)
Weight :
approx. 70 g (805590)
approx. 80 g (805591)
Dimensions (with detector) : Ø 117 mm, H = 62 mm
*3
The information applies for the entire series incl. .MAR, .N0, .NU etc.
Part No. Design
805590 Standard base ---
805591
Base with relay
contact
Potential-free contact, close/open function over solder/jumper available,
max. load capacity 30 V DC/1 A
Max. current consumption 5 µA (without detector, relay activated)
Relay is activated upon triggering of detector,
further programming in the customer data of the FACP.
Accessories
805570 IP 42 protection for detector bases, flat design
805571 Flush mount kit for detector base
805572.50 IP 43 Damp location surface-mounting base adapter for detector bases
805573 IP 43 protection for detector bases, deep design
805574 Trim ring and mounting clips
805576 Label plate e.g. for displaying the zone / detector number
805577 Mounting adapter for intermediate ceilings
805560 EMV isolator for detector base
805587
805588
805589
Cover during the construction phase or during renovation work
781550 Protective cage (Ø = 140 mm, h = 115 mm)
Commercially
option
3-pole terminal (plastic),
243-204 WAGO type (∅ 0.5 - 1.0 mm) or 273-104 WAGO type (0.75 - 2.5 mm
2
)
Diagrams of the accessory components on the following pages.
