12 esserbus
®
transponder
The esserbus
®
transponders enable conventional technology and the esserbus
®
to be connected. They are
used for different activations.
E.g. "alarm transponder" which is used for both the connection of non-addressable detectors (point-type
detectors, manual detectors and special detectors) as well as for the operation of conventional alarm signaling
devices (signaling devices, signal flasher and combination alarm signaling devices). The planning of the alarm
devices that can be connected is carried out via a calculation tool, which is part of the tools 8000 service and
programming software.
Monitoring of the lines in accordance with the latest standards is ensured via "EOL modules" (end-of-line
modules).
The IQ8FCT XS or LP can be used as a fire control transponder (FCT) for controlling and monitoring fire
protection equipment such as fire dampers, and as a technical alarm module (TAL) for monitoring an external
switching contact.
These modules with low power consumption are for interfacing to other disciplines which are not a part of the
fire detection system itself. Thanks to their intelligent concept they significantly expand the range of monitoring
and control functions as part of the building management.
Part No. Description
808623
esserbus
®
alarm transponder
808623.10
esserbus
®
transponder for UniVario
808623.40
esserbus
®
transponder SD for Special detector
808610.10
esserbus
®
transponder 12 relays
808611.10
esserbus
®
transponder 32 LED
808613.30
esserbus
®
transponder Standard Interface Extinguishing (SIE)
808619.10
esserbus
®
FSA transponder for fire doors
808606
esserbus
®
transponder IQ8FCT XS
808621
esserbus
®
transponder IQ8FCT LP, 230 V AC
804867
esserbus
®
transponder IQ8FCT
804868
Technical alarm device IQ8TAL
Part No. Accessories
808624 End-of-line element EOL-O - for alarm devices
808626 End-of-line element EOL-I - detector zone termination
808626.10 End-of-line element EOL-UV
804870 Alarm and monitoring module for IQ8TAM, IQ8TAL, IQ8FCT XS and LP
788612 Loop isolator
788603.10 Module housing for top-hat mounting rail
788600 Housing surface mount, grey
788650.10 Housing surface mount, white
788601 Housing flush mount, grey
788651.10 Housing flush mount, white
781336 DC/DC converter Output voltage 12 V DC
M200SMB Module housing surface mounting
SMB6-V0 Module housing surface mounting of up to 6 esserbus
®
transponder IQ8FCT XS
