Loop-participants and load factors
Fire detector IQ8Quad with integrated alarm devices
Part No. Description / function / device type Load factor
802382
O/So optical smoke detector
2
802383
O²T/F multisensor detector
2
802384
O²T/So multisensor detector
2
802385.xx
O²T/FSp multisensor detector
3
802386.xx
O²T/Sp multisensor detector
3
Alarm device IQ8Alarm Plus
Part No.
Alarm
Load factor
max.
Number
per loop
Visual Audible Speech Visual
Audible
(incl. Speech)
Total
807205R ---

--- --- 1,5-3,0 1,5-3,0
64
807205W
---

---
---
1,5-3,0
1,5-3,0
64
807214RR

---
---
3,0-7,9
---
3,0-7,9
32
807214WW

--- --- 3,0-7,9 --- 3,0-7,9
32
807224RR
 
--- 3,0-7,9 1,5-3,0 4,5-10,9
21
807224RW
 
---
3,0-7,9
1,5-3,0
4,5-10,9
21
807322R / -.SVxx ---
 
--- 4,0 4,0
24
807322W / -.SVxx ---
 
--- 4,0 4,0
24
807372RR.xx / .SVxx
  
3,0-7,9 4,0 7,0-11,9
13
807372RW.xx / .SVxx
  
3,0-7,9
4,0
7,0-11,9
13
The load factors, FACP battery capacity, etc. can be determined using the configuration tool at
www.esser-systems.com.
