Galaxy 3 Series Programming Manual
20
Option 24 – Print (Quick Menu Option 5)
NOTE: A serial printer must be connected to the Galaxy panel via a printer interface module, an RS232
interface module, or an on-board RS232 serial port.
This option has two sub-menus:
1 = Printer Module
2 = INT RS232 1
Each of these two sub-menus allows one of the four listed options below to be printed. Only information
corresponding to the groups assigned to the user is printed.
1 = Codes
Prints user number and name, type and groups assigned;
NOTE: only the manager can print out the user PINS; the Print Codes parameter (option 51.23) must be
enabled (default is disabled).
2 = Zones
Prints address, function, group (if group mode is enabled), status, descriptor (if assigned),
status of the chime, omit and part attributes, the RIO voltage and the zone resistance in Ohms;
3 = Log
Prints all events in the log, starting with the most recent and working backwards;
4 = All
Prints codes, zones and log details respectively.
The required option is selected by pressing the appropriate key 1-4. The printing begins immediately and can
be aborted by pressing esc.
24 - Print
