Galaxy 3 Series Programming Manual
86
Option 53 – Program Outputs
This option is used by the engineer to modify the programming of the outputs on the system. The option also
allows the attributes of the outputs to be changed. The programmable options are:
Table 19. Output Attributes
Selecting Outputs
On entering the option, the first output on the system is displayed; the output address, function and mode are
displayed on the top line, the polarity and assigned groups are displayed on the bottom line.
From the display of the first output, any output on the system can be displayed by pressing the A or B keys or
by entering the address of a specific output.
The output is selected for programming by pressing the ent key; the first output programming attribute 1=Op
Function is displayed.
53 - Program Outputs
Attributes Description
1 Output Function Assign output type
2 Output Mode 1 = Latch - requires valid code to reset
2 = Reflex - follows activation status of zones
3 = Pulse (001 - 3000 secs) - activates for programmed period
3 Output Polarity 0 = POS - 12V going to 0V in activation
1 = NEG - 0V going to 12V in activation
4 Diag. Recording Assigns output to be active during Diagnostic Test
5 Output Groups Assign groups to the output
Note: Groups only appear if the Group option is enabled
(refer to option 63.1 = OPTIONS. Groups).
