Galaxy 3 Series Programming Manual
91
53 - Program Outputs (cont’d)
Key:
S = Activates when system is set ? = Activation dependant on system programming
P = Activates when system is Part Set X = Activates during Exit Time
U = Unset E = Activates during Entry Time
A = Activated in any condition L = Switches output off if linked to destination output
- = No effect T = Activates if zone resistance is less than value for tamper s/c
O= Activates when zone is omitted or greater than value for tamper o/c
Table 22B. Output Activations per Zone
Output Functions Batt
Low
Fire Horn E/E Horn Part
Set
Confirm Line
Fail
Video Comm
Fail
Batt
Test
Wrong
CD
Alert DLYD
Fire
No
Re-arm
Timer-A
Zone Function 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29
01 Final ––SSXE– - –S–––––S –
02 Exit ––SSXE– S –S–––––S –
03 Intruder ––SSXE– S –S–––––S –
04 24 Hours ––SA – – –S–––––S –
05 Security ––SA – – –S–––––S –
06 Dual ––SSXE– S –S–––––S –
07 Entry ––SSXE– - –S–––––S –
08 Push Set ––– X – – –– –––––– –
09 Keyswitch ––– – X – –– –––––– –
10 Secure Final ––AA X S –S–––––S –
11 Part Final ––ASXEX S –S–––––S –
12 Part Entry ––AXE– S –S–––––S –
13 PA ––A– – – –– –––––A –
14 PA Silent ––– – – – –– –––––– –
15 PA Delay ––A A – – –– –––––A –
16 PA Delay Silent ––– – – – –– –––––– –
17 Link ??? ? ? ? ?? ?????? ?
18 Spare ––– – – – –– –––––– –
19 Fire –AA A – – –V––––AA –
20 Tamper ––AA – – –S–––––S –
21 Bell Tamper ––A A – – –S–––––S –
22 Beam Pair ––SSXE– – –S–––––S –
23 Battery Low U– – – – – –– ––––– – –
24 Line Fail ––– U – – A– –––––– –
25 AC Fail ––– – – – –– –––––– –
26 Log ––– – – – –– –––––– –
27 Remote Access ––– – – – –– –––––– –
28 Video ––SSXE– S –S–––––S –
29 Video Exit ––SSXE– S –S–––––S –
30 Intruder Delay ––SSXE– – –S–––––S –
31 Log Delay ––– – – – –– –––––– –
32 Set Log ––– – – – –– –––––– –
33 Custom-A ??? ? ? ? ?? ?????? ?
34 Custom-B ??? ? ? ? ?? ?????? ?
35 Exitguard LLL L L L LL LLLLLL L
36 Mask ––SSXE– – –S–––––S –
37 Urgent ––A A – – –– –––––A –
38 PA Unset ––– – – – –– –––––– –
39 Keyswitch Reset ––– – – – –– –––––– –
40 Bell fail ––– – – – –– –––––– –
41 Intr Low ––SSXE– S –S–––––S –
42 Intr High ––SSXE– S –S–––––S –
43 PSU Fault ––– – – – –– –––––– –
44–46 Not Used ––– – – – –– –––––– –
47 Vibration ––– – – – –– –––––– –
48 ATM-1 ––– – – – –– –––––– –
49 ATM-2 ––– – – – –– –––––– –
50 ATM-3 ––– – – – –– –––––– –
51 ATM-4 ––– – – – –– –––––– –
52 Alarm Extend AA– A T – –– ––––A– –
To Next Page
