Codes [42, Quick Menu 7] Galaxy Flex Installer Manual
64
To assign a level to a user:
1. Type the level to be assigned.
2. Press ent.
EN50131-1
Level
Level Access Availability
1 0
†
Guard Entered into event memory – no other option
2 1
†
Guard Can only set the system and change own PIN
2 2
†
Caretaker Can only set and unset the system and change own PIN
2 3 Users Menu options 11 to 19
2 4 Users Menu options 11 to 25
2 5 Users Menu options 11 to 32
2 6
‡
Manager Menu options 11 to 48
3 7
‡
Engineer Menu options 11 to 72
3 8
‡
Remote Menu options 11 to 72
† No access to menu functions
‡ The manager, engineer and remote codes (the last three codes on the system) have fixed
types which cannot be reprogrammed.
Note: All levels except Guard 0 can change their own PIN.
Duress Code
Entry of a Duress Code sends a signal to the monitoring station to indicate a user has been
forced to operate the system under duress. Any user on the system can be designated as a
Duress Code. There is no limit to the number of users that can be assigned as Duress Codes.
To assign a Duress Code:
In the Modify Level option, press #. The current user code is assigned as a Duress
Code.
To assign a User Code as duress:
Enable the Duress User [51.77] option.
Quick Menu
All user codes default to the quick menu. This menu is made up of a selection of ten options
(0 – 9) from the full menu. Access to the quick menu is controlled by the user type. Any
user can be upgraded from the quick menu to the full menu by assigning a
to the user
while the Modify Type option is accessed. Therefore a user with type 5 would have access
to the full menu from options 11 – 32. It is not possible to access both menus at the same
time.
To reprogram the options contained in the quick menu refer to Quick Menu [59].
Note: The master manager code defaults to the full menu.
