Operating Manual IK3 Operating Unit with Keypad18
1. Safety notes
Read the instructions carefully and thoroughly before installing the device and putting it into
operation. They contain important information on assembly, programming and operation.
The device is a state-of-the-art product. Only use the device:
- In accordance with regulations and
- When it is in a technically correct state
- In accordance with technical data.
The manufacturer is not responsible for damage that is caused by use not in acordance with
regulations.
Installation, programming as well as maintenance and repair work may only be carried out by
authorized, skilled personnel.
Soldering and connection work should only be carried out inside the entire system when it is
deenergized.
Soldering work should only be carried out using a temperature-controlled soldering bit that is
galvanically separated from the power supply.
Observe the VDE safety instructions as well as the regulations of the local power supply company.
Do not use the operating units in a potentially explosive environment or in rooms with
metal or plastic decomposing vapours.
Clean the housing with a cloth moistened with water.
Aggressive cleaning agents or chemicals may damage or discolour the
surfaces.
Table of Contents Page
1. Safety notes ..............................................................................................................................18
2. General......................................................................................................................................19
3. IK
4. Operating and indication elements.........................................................................................20
6. Possible functions ...................................................................................................................21
7. Authorization process .............................................................................................................21
8. Functions ..................................................................................................................................22
9. Appendix...................................................................................................................................30
10. FCC Statements........................................................................................................................31
data carriers .........................................................................................................................19
5. Acknowledgement signals ......................................................................................................20
3.1
8.1 Arm ......................................................................................................................................22
8.2
8.3 Hold-up alarm ......................................................................................................................24
8.4 Access control functions ......................................................................................................25
8.5
8.6
8.7 Learn mode..........................................................................................................................27
8.8 Define / alter PIN .................................................................................................................28
Possible data carriers...........................................................................................................19
3.2 Correct use of data carriers ..................................................................................................19
5.1 Optical..................................................................................................................................20
5.2 Acoustical ............................................................................................................................20
Disarm .................................................................................................................................23
Info. functions (arm/disarm) .................................................................................................25
Control functions ..................................................................................................................26
