Chapter 6 — Maintain the Printer
132 PD43 and PD43c Commercial Printer User Manual
6 Carefully slide the printhead out of the mechanism. The printhead
is still attached to the mechanism by a ribbon cable.
7 Disconnect the cable from the printhead and remove the printhead
from the printer.
8 Connect the ribbon cable to the new printhead.
9 Slide the printhead into the holders in the print mechanism.
10 Press the printhead onto the locator pins in the mechanism.
Warning: Do not touch the printhead surface area.
