Chapter 2 — Set Up the Printer
PD43 and PD43c Commercial Printer User Manual 47
Set the PD43c Rear Feed Guides
If you use the same media width all the time in the PD43c printer, you
can lock the rear feed guides in place to make loading media easier. To
lock the feed guides in place, you need a #1 Phillips screwdriver.
1 Open the printer lid.
2 Slide the feed guides to adjust them to the width of your media.
3 Tighten the adjustment screw in the center of the guide plate to
lock the guides in place. Do not overtighten.
4 If necessary, adjust the printer media guides to the width of your
media.
5 If necessary, press the release button to raise the print mechanism,
and adjust the label stop sensor.
Note: This section applies to the PD43c printer with the rear feed
guides option installed.
