Page #151 background image
Appendix A — Specifications
PD43 and PD43c Commercial Printer User Manual 137
Label Length (minimum): 6.35 mm (.25 in)
Gap Length Between Labels: 2 to 25.4 mm (0.08 to 1.0 in)
Black Mark Length 3 to 26 mm (0.12 to 1.02 in) centered
between tickets, 15% maximum
reflectance
Media Thickness: 76.2 to 221 μm (3 to 8.7 mil)
76.2 to 248.9 μm (3 to 9.8 mil) supported
when thick media springs are installed
Flexible wristbands up to 10 mils
(maximum)
Media Density:
60 to 210 g/m
2
Liner Opacity (maximum): 76% (TAPPI T425)
Ribbon Width 25.4 to 110 mm (1 to 4.33 in)
Ribbon Roll Diameter
(maximum)
68 mm (2.68 in)
Ribbon Core (I.D.) For 12.5 mm (0.5 in) core: 12 to 14 mm
(0.47 to 0.55 in)
For 25.4 mm (1.0 in) core: 25.4 to 25.8
mm (1.0 to 1.016 in)
Ribbon Core Length 110 mm (4.33 in) notched
Ribbon Wound Ink Side In or out
Label Stop Sensor Adjustable from left media edge to 4.5
mm right of center on LCD printers
(fixed at center on Icon printers)
Print Speed, Resolution, and General Media Specifications
