LYNX Touch Installation and Setup Guide
- 13 -
Installing/Configuring Communication & Home Automation Modules
5201-100-009-V3
LOCKING TABS
SCREW
(3)
SIM
CARD
ROTATED
180
CONNECTOR
BOARD
CONNECTOR
BOARD
RECEPTACLE
LYNX TOUCH
L5210
CELLULAR
COMMUNICATION
MODULE
(3GL/3GLC SHOWN)
L5210 Communications Module Installation
7000-100-016-V4
LOCKING TABS
SCREW
(3)
SIM
CARD
ROTATED
180
CONNECTOR
BOARD
CONNECTOR
BOARD
RECEPTACLE
LYNX TOUCH
L700
CELLULAR
COMMUNICATION
MODULE
(3GL/3GLC SHOWN)
L7000 Communications Module Installation
