Honeywell L5210 Series - Configuring System Settings

LYNX Touch Installation and Setup Guide
- 28 -
Programming the Control
Refer to the LYNX Touch L5210/L7000 Programming Guide (p/n 800-19976) or the LYNX Touch L5210CN/L7000 CN
Programming Guide (p/n 800-20379) for additional information regarding programming options.
System Type
The following system options are programmed in this section:
Option Function
RF Jam Enable or disable RF Jam Log and Reporting
Speaker Phone Enable or disable Speaker Phone mode. (Only available on the LYNX Touch L5210/L5210CN)
Two Way Voice Enable or disable Two Way Voice communication with the Central Station.
RF House Code Set RF House Code. (Bi-directional RF Devices)
Remote Phone Enable or disable Remote Phone Control mode. (Only available on the LYNX Touch L5210/
L5210CN)
Phone Notification Enable or disable Phone Notification mode. (Phone Line-cut) (Only available on the LYNX Touch
L5210/L5210CN)
Phone Detect Time Select a delay period between phone line-cut & system response (allows phone to restore) (Only
available on the LYNX Touch L5210/ L5210CN)
Note: This field is displayed if Phone Notification is enabled.
Events Enable or disable multiple options for event logging (i.e.; alarms, troubles, open/close, bypass, all)
Non-Security Enable or disable non-security event logging
Remote Access
Serial
Enable or disable end user to access their system via a website
Multi Mode Serial Enable or disable transmission of panel status events via email (Active only when Remote Access
Serial is enabled)
Program the Communications Module
A router is required if you are installing the L5100-WiFi module. The router must be powered on and
connected for Wi-Fi operation (alarm reporting) to occur.
The following system options are programmed in this section:
Option Function
Communications Path Selects type of Communications Module
APL Enables Advanced Protection Logic
City ID Enter Central Station Primary City ID
CS ID Enter Primary Central Station ID
Sub ID Enter Central Station Primary Subscriber ID
Supervision Selects how often the Communications Module sends supervisory messages to the Central Sta.
Old Alarm Time Selects how long an undeliverable alarm delivery is retried to the Central Station.
Remote Acc. Comm. Enables or disables user remote access via internet and/or Cellular.
Multi Mode Comm. (appears only if Remote Access IP or Cellular is enabled.) Enables/disables multi mode feature.
IP Fault Time
(Appears only if IP
or WiFi
is enabled in Communications
Path
field.) Selects time delay before
the Communications Module notifies the Control Panel of a loss of contact with the internet.
Use DHCP Dynamically selects the IP addresses
NIC IP Address (Appears only if “No” is selected in Use DHCP field.) Enter NIC IP Address.
Subnet Mask (Appears only if “No” is selected in Use DHCP field.) Enter Subnet Address.
Gateway IP Address (Appears only if “No” is selected in Use DHCP field.) Enter Gateway IP Address
DNS Server IP Address (Appears only if “No” is selected in Use DHCP field.) Enter Domain Name Server IP Address.
Cell Fault Time
(Appears o
nly if
Cellular
is enabled in Communications
Path
field.) Selects time delay before the
Communications Module notifies the Control Panel of a loss of contact with the network.
Cell Rollover
If enabled, all reports
including
sup
ervisory messages are sent over the cellular path in the event
of an Internet failure. If disabled, all reports excluding supervisory messages are sent over the
cellular path in the event of an Internet. (Appears only if “WiFi & Cellular” is selected as the
Communications Path.)
Cell 24 Hour Test
Enables daily test of
Cellular
module operation.
(Appears only if “WiFi
&
Cellular
” is selected
as
the Communications Path.)
Remote Access (Total Connect) and Multi Mode (PSD) over Wi-Fi, IP or Cellular cannot be enabled in the panel
alone. Availability of this service is controlled via the web-based programming tool on the AlarmNet 360 website.
These features must to be enabled through the AlarmNet 360 website first and transferred to the device.
