8.9 OTHER SETTINGS, CONTINUED
8.9.3 Alarm Camera Presets
If you are using a PTZ you can call the PTZ to a preset view by placing the view number
that you want to call right under the camera number. This is line 22 with the description
“Alarm Camera Views.” Since there is no way of knowing what, if any, cameras are PTZ
cameras there have been no views preprogrammed in the miniMAX package.
8.9.4 Alarm Relay Outputs
You may take the alarm response a step further by activating control output relays
against each alarm. Default alarm relays are programmed against each of the possible
alarms. These preprogrammed relay outputs along with the cameras and their
associated alarms are shown in Table 1.
Table 1. Default Alarm, Camera, and Relay
Programming
Alarm Number Camera Number Relay Number
1 1 1
2 2 1
3 3 1
4 4 1
5 5 2
6 6 2
7 7 2
8 8 2
9 9 3
10 10 3
11 11 3
12 12 3
13 13 4
14 14 4
15 15 4
16 16 4
17 17 5
18 18 5
19 19 5
20 20 5
21 21 6
22 22 6
23 23 6
24 24 6
25 25 9
