Rev. 1.0 22 900.0688
9-Dec-05
8.7 DEFINING LOGICAL CAMERA SELECTIONS
Logical Camera Selection provides an alternative method of selecting cameras whereby
a keyboard key is defined for each logical group name. Camera selection is made by
selecting the desired group, plus a numeric entry. For example, to select the first
camera in the “entrance” (which may be any camera number), the operator would select
<ENTRANCE> <1>.
Default logical groups are defined on MAX-1000 keyboards and in the system
configuration. To edit the name of a logical group, select the L
ogical Camera Selection
tab and type the new name for the logical group into the LOGICAL GROUP
DESCRIPTION field.
