24
Enable Low-Contrast
Data Matrix Decoding
†
* Disable Low-Contrast
Data Matrix Decoding
³125417
Improves decoding
†
of
low-contrast Data
Matrix symbols.
³125407
Enable Data Matrix
Non-Square Modules
†
* Disable Data Matrix
Non-Square Modules
³125416
Improves decoding
†
of
Data Matrix symbols
when individual modules
in the symbol are non-
square.
³125406
Enable Data Matrix
Shifted Tiles
†
* Disable Data Matrix
Shifted Tiles
³125415
Improves decoding
†
of Data
Matrix symbols when the
upper tiles in the symbol are
shifted in the symbol
relative to the bottom tiles.
³125405
*
Factory default configuration
†
Enabling these options will increase decoding time for all bar codes.
