Imager Operation
Presentation and Trigger
†
Modes
There are four configurable modes for scanning: the presentation mode,
the multi-try trigger mode, the continuous trigger mode, and the single-trigger
mode. These modes can be configured separately for in-stand and out-of-stand
imager operation
‡
.
In-Stand
‡
* Presentation Mode
In-Stand
Multi-Try Trigger Mode
In-Stand
³420204 ³420224
Continuous Trigger Mode
In-Stand
Single Trigger Mode
In-Stand
³420254 ³420244
* Factory default configuration.
†
The term trigger and button are synonymous.
‡
In-Stand and Out-of-Stand references are not applicable for all products.
