Chapter 1 - Masterlogic components
Items
2MLP-
ACF1
2MLP-
ACF2
2MLP-AC23 2MLP-DC42
Output1 Output voltage DC 5V (±2%) DC5V (±2%)
Output current 3.0A 6.0A 8.5A 6.0A
Over current protect 3.2A or
more
6.6A or
more
9.0A or
more
6.6A or more
Over voltage protect 5.5V ~ 6.5V
Output2 Output voltage DC 24V
(±10%)
- -
Output current 0.6A
Over current protect 0.7A or
more
Over voltage protect None
Relay
Output
Application RUN contact (Refer to the section 8.3)
Rated switching
voltage or current
DC 24V, 0.5A
Minimum
switching load
DC 5V,1 mA
Response time OFF→ON/ ON→OFF: 10 ms or less/12 ms or less
Life Mechanical: More than 20,000,000 times
Electrical: More than 100,000 times at rated switching
voltage/current
RUN signal output Relay output, Rating: DC24V, 0.5A
Voltage indicator Output voltage normal, LED ON
Cable specification 0.75 ~ 2mm
2
Compressed terminal RAV 1.25 - 3.5, RAV 2 - 3.5
Weight 0.4kg 0.6kg 0.5kg
ATTENTION
1. Allowable Momentary Power Failure Time: It is the time that the input voltage keeps
normal output voltage (normal operation) in the state that AC 110/220V voltage is lower
than the rated value (AC85/170V).
- 4 -
