Extinguishing control panel. User manual
22 June 2011 10
VSN-4REL and VSN-232 connections
VSN4-REL FUNCTIONS
Relay 1
Fire Zone 1
Relay 2 Fire Zone 2
Relay 3 Fire Zone 3
Relay 4 Preactivation
or Activation
V
SN-4REL
V
SN-232
IN
