CHAPTER
1
PW-7000 (PW7K1IC) Installation and Configuration Guide, Document 800-25673V1 13
PRODUCT OVERVIEW
The Intelligent Controller is the heart of the PW-7000 and provides the real time
processing for the connected I/O interfaces.
The PW-7000 is designed to operate without the need for a PC. It can be connected
to a Pro-Watch host computer using TCP/IP network connection. The PW-7000
holds the database for the subsystem configuration and card holders, and the
event log buffer, which is in battery-backed memory.
Note: Please refer to the Pro-Watch Software Suite Guide for details on using the Pro-
Watch interface.
PW-7000 and PW-6000
The PW-7000 controller configuration and operation is similar to the PW-6000
controller and has additional R2 functions on board; both use the Pro-Watch front
end.
The PW-7000 controller is compatible with the following Honeywell modules;
PW7K1R2, PW7K1IN, PW7K1OUT, PW6K1R2, PW6K1IN, and PW6K1OUT.
Port Settings
• Port 0 provides the host-embedded Ethernet interface.
• Ports 1 for RS-485 2-wire downstream support for connecting 32 I/O devices.
Note that the I/O communications must be mapped differently in Pro-Watch,
according to the following table:
PW-7000 Port Pro-Watch Port
1
1
