8 796689 (4188-658) i2_04/07
Controls and
indicators
Audible
indication
While reading the instructions it may help to
open out the back page of this manual to
view the location of controls and indicators
on the panel. For description of controls and
indicators see User controls and indicators
section.
There is a cancellable buzzer in the panel
that operates automatically to announce Fire
and Fault events.
Navigation
Previous
Next
Esc
The buttons to navigate the menu and to
select a menu option at the panel are the
Enter, Previous, Next and Esc buttons.
The Enter button will display the top-level
menu or accept a selection.
The menu bar displayed
here shows the menu
available at access level 1.
The Previous and Next buttons can be used
to scroll and select a menu option.
The Esc button performs a quit function.
Pressing the Esc button will close an open
menu or sub-menu and return it to the
previous display.
