Supported remote-removable media for Windows operating system
The Windows operating system removable media drives can be mounted in an Icon Series console,
with an IDE to USB or eSATA to USB cable adapter. The following table provides specifications for the
removable media.
Maximum weight and dimensions
Description Height Width Depth Weight
CDRW/DVDRW 40.64 mm 146.05 mm 14.22 mm 1.20 kg
2.4 Specific slot configuration
NOTE
A Local Control Network Processor (LCNP) board and LCN Media Access Unit (MAU) are no
longer used if the Workstation has been upgraded to be an ELCN node.
The Honeywell-configured Dell Precision T5810XL workstation is available in dual video graphics as a
default option. The workstation supports both triple screen and quad screen video capabilities by
adding an additional nVIDIA NVS 315 (MZ-DUAL04) with the existing default nVIDIA NVS 315 video
card.
The following board configuration layouts specify the available system configuration sets.
l Basic board configuration
l Basic board configuration for single/dual screen Experion (T-node) systems
l Basic board configuration for quad screen Experion (T-node) systems
l Basic board configuration for single/dual screen Experion (ES-C/ES-F) FTE systems
l Basic board configuration for quad screen Experion (ES-C/ES-F) FTE systems
l Basic board configuration using Wyse RPS for Experion (TP-THNCL2/3)
l Basic board configuration using Matrox Extio2 RPS for Experion ES-C/ES-F (TP-RPSF02)
l Basic board configuration using Matrox Extio2 RPS for Experion ES-T (TP-RPSF02)
l Basic board configuration using nVIDIA NVS 510
l Basic board configuration for dual screen PCUS (dual LCN) systems
l Basic board configuration for dual screen PCUS (single LCN) systems
2.4.1 Basic board configuration
The following table describes the standard basic board configuration for the workstation.
- 18 -
Chapter 2 - Planning
