Chapter 2 - Planning
External peripherals
External peripherals Specifications
Keyboard USB Windows compliant (equivalent or better)
Mouse USB optical 2-button w/scroll (equivalent or better)
Drives
Drives Specifications
Diskette drives None
Storage
controller
Integrated Intel(R) C600+/C220+ series chipset sSATA RAID
Controller
Hard drive 2-500 GB SATA III (512 byte or AFD) or larger,
(Or)
7.2K RPM w/ 16 MB DataBurst Cache (minimum) in RAID1
configuration.
Audio
Audio type Realtek ALC3220 audio codec
Standard ports
I/O
ports Specifications
Front One USB 3.0, three USB 2.0, one Headphone, and one Microphone
Internal Three USB 2.0
Rear Three USB 3.0, three USB 2.0, one serial, one audio line-in, one audio line-
out, two PS/2, and one RJ45 NIC
2.3.2 Removable media specifications
The system is configured with one (1) removable media drive that is a SATA CD-RW/DVD±RW combo
drive. The SATA CD-RW/DVD±RW drive is connected to a SATA port connector on the motherboard.
- 17 -
