2.4.8 Basic board configuration using Matrox Extio2 RPS for
Experion ES-T (TP-RPSF02)
The following table describes the standard basic board configuration using Matrox Extio2 RPS for
Experion ES-T (TP-RPSF02).
Slot number Slot type Description
6 PCI 32 /33
5 PCIe Gen2 x4
4 PCIe Gen3 x16
3 PCIe Gen2 x1 Broadcom dual port X1 gigabit NIC adapter
2 PCIe Gen3 x16 Extio F2408
1 PCIe Gen3 x4 LCNP4E / LCNP4e2
2.4.9 Basic board configuration using nVIDIA NVS 510
The following table describes the standard basic board configuration for nVidia NVS510
Slot number Slot type Description
6 PCI Serial COM1 adapter cable
5 PCIe Gen2 x4
4 PCIe Gen3 x16
3 PCIe Gen2 x1
2 PCIe Gen3 x16 nVidia NVS 510
1 PCIe Gen3 x8
2.4.10 Basic board configuration for dual screen PCUS (dual LCN)
systems
The following table describes the standard basic board configuration for dual LCN PCUS.
- 22 -
Chapter 2 - Planning
