Chapter 2 - Planning
Slot number Slot type Description
6 PCI Empty or power adapter harness
5 PCIe Gen2 x4
4 PCIe Gen3 x16 nVIDIA NVS 315
3 PCIe Gen2 x1 Broadcom dual port X1 gigabit NIC adapter
2 PCIe Gen3 x16 nVIDIA NVS 315
1 PCIe Gen3 x8
2.4.6 Basic board configuration using Wyse RPS for Experion (TP-
THNCL2/3)
The following table describes the standard basic board configuration using Wyse RPS for Experion.
Slot number Slot type Description
6 PCI
5 PCIe Gen2 x4
4 PCIe Gen3 x16
3 PCIe Gen2 x1 Broadcom dual port X1 gigabit NIC adapter
2 PCIe Gen3 x16 nVIDIA NVS 315
1 PCIe Gen3 x8
2.4.7 Basic board configuration using Matrox Extio2 RPS for
Experion ES-C/ES-F (TP-RPSF02)
The following table describes the standard basic board configuration using Matrox Extio2 RPS for
Experion ES-C / ES-F (TP-RPSF02).
Slot number Slot type Description
6 PCI 32 /33
5 PCIe Gen2 x4
4 PCIe Gen3 x16
3 PCIe Gen2 x1 Broadcom dual port X1 gigabit NIC adapter
2 PCIe Gen3 x16 Extio F2408
1 PCIe Gen3 x4
- 21 -
