Chapter 2 - Planning
Slot number Slot type Description
6 PCI Empty or power adapter harness
5 PCIe Gen2 x4
4 PCIe Gen3 x16 LCNP4e-2 / LCNP4e2-2
3 PCIe Gen2 x1
2 PCIe Gen3 x16 nVIDIA NVS 315
1 PCIe Gen3 x8 LCNP4e-1 / LCNP4e2-1
ATTENTION
PCUS does not support FTE. Enable the onboard NIC controller in the system BIOS to use it as
an Ethernet.
2.4.11 Basic board configuration for dual screen PCUS (single LCN)
systems
The following table describes the standard basic board configuration for single LCN PCUS.
Slot number Slot type Description
6 PCI Empty or power adapter harness
5 PCIe Gen2 x4
4 PCIe Gen3 x16
3 PCIe Gen2 x1
2 PCIe Gen3 x16 nVIDIA NVS 315
1 PCIe Gen3 x8 LCNP4e-1 / LCNP4e2
ATTENTION
PCUS does not support FTE. Enable the onboard NIC controller in the system BIOS to use it as
an Ethernet.
2.5 Memory configuration
8 GB (2x4 GB) RDIMM ECC is the standard installed memory for TAB 100 model systems. It is
recommended that the memory devices must be from the same supplier and must be of the same type
and technology.
- 23 -
