Chapter 2 - Planning
Slot number Slot type Description
6 PCI
5 PCIe Gen2 x4
4 PCIe Gen3 x16
3 PCIe Gen2 x1
2 PCIe Gen3 x16 nVIDIA NVS 315
1 PCIe Gen3 x8
2.4.2 Basic board configuration for single/dual screen Experion (T-
node) systems
The following table describes the standard basic board configuration for single/dual screen Experion (T-
node) systems.
Slot number Slot type Description
6 PCI Empty or power adapter harness
5 PCIe Gen2 x4
4 PCIe Gen3 x16
3 PCIe Gen2 x1 Broadcom dual port X1 gigabit NIC adapter
2 PCIe Gen3 x16 nVIDIA NVS 315
1 PCIe Gen3 x8 LCNP4E / LCNP4e2
- 19 -

Honeywell T5810XL Specifications

General

Brand	Honeywell
Model	T5810XL
Category	Desktop
Language	English
