Vibration
Operating 5 Hz to 350 Hz at 0.0002 G
3
/Hz
Storage 5 Hz to 500 Hz at 0.001 to 0.01 G
3
/Hz
Maximum Shock
Operating 40 G +/- 5% with pulse duration of 2 m/sec +/- 10% (equivalent to
51 cm/sec [20 in/ sec])
Storage 105 G +/- 5% with pulse duration of 2 m/sec +/- 10% (equivalent to
127 cm/sec [50 in/ sec])
NOTE
*ANSI/ISA-S71.01-1985 Environmental Conditions for Process Measurement and Control
Systems: Temperature and Humidity.
NOTE
**ANSI/ISA-S71.04-1985 Environmental Conditions for Process Measurement and Control
Systems: Airborne Contaminants.
Form factor
Form factor Specifications
Form Factor/Configuration Tower
Height (with feet) 16.41 inches (416.90 mm)
Width 6.79 inches (172.60 mm)
Depth 18.54 inches (471.00 mm)
Weight (Minimum) 13.50 Kg (29.80 lb)/12.40 kg (27.40 lb)
Drive bays
Drive bays Specifications
Internal Two 3.5 inches
External One slim ODD
One 5.25 inches
- 16 -
Chapter 2 - Planning
