T775R SERIES 2000 ELECTRONIC STAND-ALONE CONTROLLER
23 62-0249—13
Fig. 55. Setup - Outputs - Modulating Output Menu.
3.3.3.1. Setting up the Modulating
Outputs
1. From the Output menu, use the  and  buttons to
highlight the desired modulating output (MOD 1 or
MOD 2).
2. Press the  button to display the selected MOD
menu.
NOTE: Modulating outputs are not available on
controller models T775R2001 and
T775R2035. If you are setting up one of these
controllers, skip to “3.3.4. NBR OF RELAYS”
on page 25.
Use the remaining procedures, beginning with “3.3.3.1.1.
TYPE (of output signal)”, to set up each modulating
output. If you have two modulating outputs, repeat these
procedures for each modulating output.
Fig. 56. Setup - Outputs - Mod Out - Type.
3.3.3.1.1. TYPE (of output signal)
1. From the Mod menu, use the  and  buttons to
highlight TYPE.
2. Press the  button to display the Type selections.
3. Use the and  buttons to highlight the desired
output type.
Default: 4-20 mA
4. Press the  button to accept the selected type and
return to the Mod menu.
Fig. 57. Setup - Outputs - Mod Out - Minimum
Output Percentage.
3.3.3.1.2. MIN OUT %
The minimum output % prevents the output from dropping
below the value entered. This value can be useful to
maintain minimum damper position.
Using the time clock or digital input to disable the output
forces the output to 0%.
1. From the Mod menu, use the  and  buttons to
highlight MIN OUT %.
2. Press the  button to display the Min Out %.
3. Use the  and  buttons to increase/decrease the
desired value from 0% to 100% in 1% increments.
Default: 0%
Range: 0 to 100%
4. Press the  button to accept the percentage and
return to the Mod menu.
Fig. 58. Setup - Outputs - Mod Out - Integral.
3.3.3.1.3. INTEGRAL
1. From the Mod menu, use the  and  buttons to
highlight INTEGRAL.
2. Press the  button to display the Integral seconds.
3. Use the  and  buttons to increase/decrease the
value from 0 to 3,600 in 10 second increments.
Default: 400 seconds
Range: 0 to 3,600 seconds
4. Press the  button to accept the seconds and
return to the Mod menu.
SETUP
OUTPUTS
MOD 1
SETUP
OUTPUTS
MOD 1
TYPE
MIN OUT %
INTEGRAL
DERIVATIV
SCHEDULE
RESET
EXIT
M24334
SETUP
OUTPUTS
MOD 1
TYPE
SETUP
OUTPUTS
MOD 1
TYPE
SELECT
TYPE FOR
MOD 1
4 - 20 mA
0-10 V
2-10 V
SERIES 90
M24335
SETUP
OUTPUTS
MOD 1
MIN OUT %
ENTER
MINIMUM
PERCENT FOR
MOD 1
SETUP
OUTPUTS
MOD 1
MIN OUT %
0
%
M24336
SETUP
OUTPUTS
MOD 1
INTEGRAL
ENTER
INTEGRAL
TIME FOR
MOD 1
SETUP
OUTPUTS
MOD 1
INTEGRAL
400
SEC
M24337
